Epoxy Oil Resistant Conductive Anti-static Top Coat Technical Parameter
-
Product Technical Parameters
-
Matching cleaning agents and diluents
-
Surface treatment and painting
Consulting Technology
Project | ||
Colour | Grey | |
Status in the container | No hard lumps after mixing and homogeneous | |
Constructability | Coating barrier-free | |
Film appearance | Flat and smooth | |
Gloss (60°)/°, ≥ | 50 | |
Fineness/μm, ≤ | 50 | |
Drying time/h, ≤ | Table dry | 1.5 |
Actual drying | 24 | |
Non-volatile fraction/%, ≥ | 75 | |
Surface resistance | 105 -109 Ω | |
Density, g/ml | 1.5±0.05 | |
VOC (Factory value), ≤ | 220mg/L | |
Recommended dry film thickness | 40-100µm | |
Theoretical coating rate (40µm) | 0.09kg/㎡ | |
Application period (25°C)/h, ≥ | 6 | |
The ratio of the main agent and the curing agent is 8 : 1, and the epoxy diluent is added 10-15 %,
Steel surface treatment according to the national standard "steel surface rust grade and rust removal grade before painting" GB8923-88 implementation, sandblasting rust removal to achieve the national standard Sa2.5 grade, manual rust removal to achieve St3 grade.
Construction method
The high-pressure airless spraying, brushing, and rolling are applied.
